Polyethylene

LLDPE (Linear Low Density Polyethylene) HDPE (High Density Polyethylene)
PE is a primary component in a varieties of products such as
Food packaging material・shopping bag

LLDPE Manufacturing Process

Page Top

LLDPE(Linear Low Density Polyethylene)"QAMAR"

QAMAR is a brandname of LLDPE (butene type) produced by Eastern Petrochemical Company "SHARQ" using Unipol process and solely marketed through SPDC LTD.

【QAMAR GRADE MAP】

Characteristics MI=0.5 MI=1 MI=2 MI=2.8
Standard Clarity - FC21HN FD21HN -
High Clarity - FC21HS FD21HS -
LDPE blended - FC20H - -
Non-Slip & Non-Antiblocking Agent HB18N FC18N FD18N CD18N
Page Top

HDPE(Hig Density Polyethylene) "QAMAR-HD"

QAMAR-HD is a brandname of HDPE (butene type) produced by Eastern Petrochemical Company "SHARQ" using Unipol process and solely marketed through SPDC LTD.

【QAMAR-HD RESIN PROPERTIES】

Item Grade F1
Test Method Unit
MI*1 ISO 1872-2 g/10min 0.05
HLMI*2 ISO 1872-2 g/10min 9
Density ISO 1872-2 g/cm3 0.952
Melting Point ISO 11357-3 ºC 132
Vicat Softening Temperature ISO 306 ºC 125
Additives Antioxidants
Recommended Processing Method Blown Film Fabrication
Applications Grocery Sacks
Shopping Bags
Processing Characteristics Stability
Film Characteristics Stiffness
Strength

【QAMAR-HD FILM PROPERTIES】

Item Grade F1
Test Method Unit
MI*1 ISO 1872-2 g/10min 0.05
HLMI*2 ISO 1872-2 g/10min 9
Density ISO 1872-2 g/cm3 0.952
Film Tickness - µm 20
Haze ISO 14782 % 50
Dart Drop Impact ISO 7765 g 150
Tensile Stress at Break MD ISO 527-3 MPa 60
TD 55
Nominal Tenslle Strain at Break MD ISO 527-3 % 270
TD 610
Modulus of Elasticity in Tension MD ISO 527-3 MPa 1,350
TD 1,550
Elmendorf Tear Strength MD ISO 6383-2 N/mm 5
TD 35
Processing Conditions Resin Temparature 200ºC
Blow up Ratio 3
Extruder 50mm L/D=28
Air Ring SINGLE SLIT
Die 100mm LIP GAP=1mm
Output 60kg/h
Take off Speed 60m/min

*1 Melt Index(2.16kg)
*2 High Load Melt Index (21.6kg)

The information on above tables shows typical properties and characteristics only and intended as guide, not as specification.
The product mentioned herein is not permitted to use medical, pharmaceutical, healthcare applications and we do not support their use for such applications.

Disclaimer
To the best of our knowledge, the information contained herein is accurate as of the date of issue, however we do not assume any liability whatsoever for the accuracy and completeness of such information. The customer shall hold responsibility for the decision of suitability for the customer's particular product. we assume no liability with regarding to this suitability. All IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE ARE CLEARLY EXCLUDED. No liability can be accepted in respect of the use of SPDC's products in conjunction with other materials.
