【QAMAR GRADE MAP】

【QAMAR-HD RESIN PROPERTIES】

【QAMAR-HD FILM PROPERTIES】

Item		Grade		F1
		Test Method	Unit
MI*1		ISO 1872-2	g/10min	0.05
HLMI*2		ISO 1872-2	g/10min	9
Density		ISO 1872-2	g/cm3	0.952
Film Thickness		-	µm	20
Haze		ISO 14782	%	50
Dart Drop Impact		ISO 7765	g	150
Tensile Stress at Break	MD	ISO 527-3	MPa	60
	TD			55
Nominal Tensile Strain at Break	MD	ISO 527-3	%	270
	TD			610
Modulus of Elasticity in Tension	MD	ISO 527-3	MPa	1,350
	TD			1,550
Elmendorf Tear Strength	MD	ISO 6383-2	N/mm	5
	TD			35
Processing Conditions		Resin Temperature		200ºC
		Blow up Ratio		3
		Extruder		50mm L/D=28
		Air Ring		SINGLE SLIT
		Die		100mm LIP GAP=1mm
		Output		60kg/h
		Take off Speed		60m/min

*1 Melt Index(2.16kg)
*2 High Load Melt Index (21.6kg)

The information on above tables shows typical properties and characteristics only and intended as guide, not as specification.
The product mentioned herein is not permitted to use medical, pharmaceutical, healthcare applications and we do not support their use for such applications.

Disclaimer
To the best of our knowledge, the information contained herein is accurate as of the date of issue, however we do not assume any liability whatsoever for the accuracy and completeness of such information. The customer shall hold responsibility for the decision of suitability for the customer's particular product. we assume no liability with regarding to this suitability. All IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE ARE CLEARLY EXCLUDED. No liability can be accepted in respect of the use of SPDC's products in conjunction with other materials.
